POWERCON TRUE1 CABLE CONNECTOR OUTLET FOR 10-16MM OD CABLE

NEUNAC3F-TRUE1-L

NAC3F-TRUE1-L

New product

Balcatta: 0
Geebung: 0

NAC3F-TRUE1-L Lockable PowerCON TRUE1 Cable Connector (IP65/IP67)

The NAC3F-TRUE1-L is a heavy-duty locking cable connector from Neutrik’s powerCON TRUE1 series, engineered for safe and rugged AC power connections in harsh environments. This true mains connector features breaking capacity (CBC), allowing it to be connected or disconnected under live load conditions. Certified to IEC 60320-1, UL 60320-1, and CSA standards, it supports 16 A at 250 V AC (Europe) and 20 A at 250 V AC (US/Canada), ensuring global electrical compliance. Built with UV-resistant polyamide and a secure twist-lock mechanism, it offers reliable cable retention for diameters from 10 to 16 mm.

Designed to withstand extreme outdoor and industrial use, the NAC3F-TRUE1-L delivers IP65/IP67 protection when mated or sealed, with flammability rated to UL 94 V-0 and a wide operating temperature range. The connector supports up to 5000 mating cycles, accommodates 1.0–2.5 mm² wires (14–12 AWG), and features silver-plated copper alloy contacts. It is ideal for professional AV setups, stage power distribution, and other demanding applications requiring a robust and secure power interface:contentReference[oaicite:0]{index=0}.

Key Features

  • Lockable 250V AC power connector with breaking capacity (CBC)
  • Rated 16 A (EU) and 20 A (US/Canada) for heavy-duty applications
  • IP65/IP67 environmental protection when mated or sealed
  • Compatible with cable O.D. 10–16 mm, wire sizes 1.0–2.5 mm²
  • Durable polyamide housing with UV resistance and >5000 mating cycles
  • PRODUCT TYPE CONNECTORS
  • COLOR BLACK
