> >>>TOA IR820SP IR-820SP 4.72" 20W CEILING MOUNTED INFRARED SPEAKER WHITE
TOA IR820SP 20W CEILING SPEAKER WHITE View larger

TOA

TOA IR820SP IR-820SP 4.72" 20W CEILING MOUNTED INFRARED SPEAKER WHITE

TOAIR820SP

IR820SP

New product

Balcatta: 0
Geebung: 0

TOAIR820SP TOA IR-820SP Infrared Wireless Classroom Ceiling Speaker - 20 W White

The TOA IR-820SP is a ceiling-mounted powered infrared speaker designed for classroom PA systems in rooms of approximately 10 m x 10 m. Its integrated receiver provides 360° horizontal reception for separate teacher and student channels, while a 20 W Class D amplifier and 12 cm full-range driver deliver a 100 Hz to 20 kHz frequency response.

Designed for use with compatible TOA infrared wireless microphones and the IR-802T Infrared Wireless Tuner, the system supports simultaneous operation in adjacent classrooms while reducing interference and eavesdropping concerns. The IR-820SP receives 24 V DC power from the tuner and connects using CAT-5 UTP cable through its RJ45 terminal.

Key Features

  • Separates teacher and student audio through two dedicated infrared channels
  • Maintains reliable reception around the room through a 360° horizontal receiving angle
  • Allows neighbouring classrooms to operate compatible systems simultaneously with improved signal isolation
  • Combines infrared reception, digital amplification and full-range sound in one ceiling-mounted unit
  • Uses a single CAT-5 connection to link with and receive power from the compatible IR-802T tuner
  • Colour White
  • Sensitivity 100 dB
  • Warranty 3 Years
  • PRODUCT TYPE INFRARED SPEAKER
  • COLOR WHITE
  • Brand TOA
  • Driver Size 4.72"
  • Mount Type CEILING MOUNTED
  • Dispersion Angle 360
  • Input Connector RJ-45
  • Weight (kg) 3.1 KG
  • LF Driver Size 4.72"
  • Enclosure STEEL PLATE
  • Hertz 100-20000HZ (-10dB)
  • Max Wattage 20W
  • Pair SINGLE
  • Amp Power (W) 20W
  • Dia (mm) 320
  • Amp Class D
  • Series IR-820SP
