> >>>EV EVL-EVID-EC6.2 EVID-EC 6.5" 2-WAY COAXIAL 100V LINE 30W IP34 8 OHM CEILING SPEAKER PAIR WHITE
ELECTRO-VOICE EVID-EC6.2 CEILING LOUDSPEAKER - ECONOMY SERIES (1X PAIR) View larger
Previous Next

ELECTROVOICE

EV EVL-EVID-EC6.2 EVID-EC 6.5" 2-WAY COAXIAL 100V LINE 30W IP34 8 OHM CEILING SPEAKER PAIR WHITE

ELEEVID-EC6.2

EVL-EVID-EC6.2

New product

ELECTRO-VOICE EVID-EC6.2 6.5 INCH 2-WAY COAXIAL CEILING SPEAKER 70/100V (PAIR) WHITE

More details

Balcatta: 0
Geebung: 0

ELEEVID-EC6.2 Electro-Voice 6.5-Inch Coaxial Ceiling Speakers 70/100 V - Pair

The Electro-Voice EVID-EC6.2 is a pair of 6.5-inch coaxial two-way ceiling loudspeakers for professional installed audio. Each speaker uses an internal transformer with selectable taps up to 30 W for 70 V or 100 V lines, together with an 8-ohm bypass for low-impedance operation.

Designed for indoor drop-ceiling installations, each unit has an IP34 rating and an operating temperature range of 0 °C to 40 °C. A heavy-gauge coated-steel rear enclosure, UL 94V-0-rated ABS baffle and semi-gloss white powder-coated steel grille provide a robust ceiling installation, with a mounting ring and tile bridge supplied for fibre-based ceiling tiles.

Key Features

  • Broad 80 Hz to 20,000 Hz frequency response supports clear ceiling-speaker reproduction
  • Wide 110° conical coverage helps distribute sound across the listening area
  • Supports capable installed output with 50 W continuous power handling and a calculated 109 dB continuous maximum SPL
  • Low-profile 148 mm mounting depth helps fit installations with restricted ceiling space
  • Pass-through wiring supports efficient extension to additional loudspeakers
  • Colour White
  • Impedance 8 ohm
  • IP Rating IP34
  • Sensitivity 92 dB
  • Warranty 3 Years
  • PRODUCT TYPE CEILING SPEAKER
  • COLOR WHITE
  • Brand EV
  • Config 2-WAY COAXIAL
  • Driver Size 6.5"
  • Power Type 70V/100V LINE
  • Mount Type CEILING MOUNTED
  • SPL (DB) 109
  • Dispersion Angle 110
  • Input Connector 4-PIN EUROBLOCK
  • Peak Power (W) 200W
  • Weight (kg) 2.8 KG
  • HF Driver Size 1"
  • LF Driver Size 6"
  • Enclosure STEEL
  • Max SPL (dB) 115 DB
  • Hertz 80-20000HZ (-10dB)
  • Max Wattage 50W
  • Max 100V Tap (W) 30W
  • 100V Taps List 30W; 15W; 7.5W; 3.75W
  • Max 70V Tap (W) 30W
  • 70V Taps List 30W; 15W; 7.5W; 3.75W; 1.88W
  • Pair PAIR
  • Dia (mm) 302
  • Series EVID-EC
