HH TNI-C4-WH TESSEN INSTALL 4" 2-WAY COAXIAL PASSIVE 180W 8 OHM CEILING SPEAKER WHITE

HHATNI-C4-WH

TNi-C4-WH

New product

HH ELECTRONICS TNI-C4-WH 4 INCH CEILING PASSIVE SPEAKER 30W 70V/100V/8OHM WHITE

More details

Balcatta: 0
Geebung: 0

TNi-C4-WH HH 4 Inch Two-Way Back Can Ceiling Speaker - White 70 V 100 V or 8 Ohm

The HH TNi-C4-WH is a compact passive two-way bass-reflex ceiling loudspeaker with an integrated back can, 4-inch paper woofer and 1.5-inch neodymium tweeter. Its front-facing selector provides 30 W, 15 W and 6 W taps for 100 V lines, 15 W, 7.5 W and 3 W taps for 70 V systems, or direct 8-ohm operation rated at 45 W AES.

Designed for restricted mounting areas, the speaker uses a white ABS surround and circular mesh steel grille for a clean ceiling finish. Spring terminals and three locking dog-ear brackets assist secure connection and mounting, while the power selector remains accessible after installation.

Key Features

  • 100 Hz to 16 kHz response at -3 dB supports balanced speech and music reproduction
  • Calculated maximum SPL of 111 dB provides useful headroom for compact ceiling audio
  • Wide 130° conical coverage helps distribute sound across a broad listening area
  • Low 1.4 kg unit weight supports practical handling during overhead installation
  • Installation grip range of 4-20 mm accommodates varied ceiling panel thicknesses
  • Colour White
  • Impedance 8 ohm
  • Sensitivity 88 dB
  • Warranty 2 Years
  • PRODUCT TYPE CEILING SPEAKER
  • COLOR WHITE
  • Brand HH
  • Config 2-WAY COAXIAL
  • Driver Size 4"
  • Power Type PASSIVE
  • Mount Type CEILING MOUNTED
  • Dispersion Angle 130
  • Input Connector PUSH SPRING CONNECTORS
  • Peak Power (W) 180W
  • Weight (kg) 1.4 KG
  • HF Driver Size 1.5"
  • LF Driver Size 4"
  • Enclosure ABS PLASTIC
  • Max SPL (dB) 111 DB
  • Hertz 85-20000HZ
  • Max Wattage 180W
  • Series TESSEN INSTALL
