PARRX8TD-566 Parallel RX8TD UHF True Diversity Receiver Module 520-675MHz-100-Frequencies-2-Way-Sync-12VDC

The PARRX8TD-566 is a professional UHF true diversity wireless receiver module designed for reliable wireless microphone and audio distribution systems in live sound, broadcast, houses of worship, and installed AV. Covering 520-675MHz with 100 switchable frequencies and up to 25MHz switching bandwidth, it features PLL synthesised tuning, a helical filter RF front end, and tight ±0.005% frequency stability to help deliver clean, dropout-resistant reception.

Ideal for rack builds, mixer integration, and custom RF installations, it supports patented IrDA 2-way synchronisation with matched transmitters plus RF noise and Pilotone squelch for strong interference control. The LCD provides fast setup and monitoring (channel, frequency, RF/AF levels, antenna selection, and transmitter battery), while balanced (+10dBm/2.5V) and unbalanced (+4dBm/1.25V) audio outputs and a 20-pin connection simplify professional integration on 12V DC power.

Key Features

  • UHF 520-675MHz tuning with 100 switchable frequencies and frequency scan for fast coordination
  • True diversity reception with helical filter front end for high selectivity and stable performance
  • IrDA 2-way sync plus LCD status display for quick setup and clear RF/AF monitoring
  • High RF performance: -100dBm sensitivity, >110dB S/N, >85dB image and spurious rejection, <0.5% THD
  • Balanced and unbalanced audio outputs, 20-pin install connector, compact 73x36x138mm module powered by DC 12V
  • PRODUCT TYPE RECEIVER
  • COLOR BLACK
