> >>>ELECTRO VOICE EVL-ZX1I-90T ZX1I 8" 2-WAY PASSIVE 800W IP44 8 OHM SURFACE MOUNTED 2-WAY INDOOR/OUTDOOR INSTALL LOUDSPEAKER BLACK
New ELECTRO VOICE EVL-ZX1I-90T ZX1I 8" 2-WAY PASSIVE 800W IP44 8 OHM SURFACE MOUNTED 2-WAY INDOOR/OUTDOOR INSTALL LOUDSPEAKER BLACK View larger

ELECTRO VOICE

ELECTRO VOICE EVL-ZX1I-90T ZX1I 8" 2-WAY PASSIVE 800W IP44 8 OHM SURFACE MOUNTED 2-WAY INDOOR/OUTDOOR INSTALL LOUDSPEAKER BLACK

ELEZX1I-90T

EVL-ZX1I-90T

New product

Balcatta: 0
Geebung: 0

ELEZX1I-90T Electro-Voice ZX1i 8-Inch Two-Way Passive Indoor Outdoor Installation Loudspeaker - 90° x 50° 70/100 V Black

The Electro-Voice ZX1i-90T is an 8-inch two-way passive full-range loudspeaker configured for 70 V and 100 V distributed audio systems, with selectable transformer taps and an 8 ohm bypass. It combines an EV8L weatherised low-frequency driver, a DH2005 1-inch-exit compression driver and a high-impact ABS resin enclosure in a compact fixed-installation format.

Patented ASC Automatic Saturation Compensation prevents transformer saturation at low frequencies, helping protect the driving amplifier from saturation-related overload and distortion while supporting a consistent 50 Hz high-pass approach across multi-speaker lines. The integrated QuickSAM mounting system enables snap-fit placement and final position adjustment for efficient installation.

Key Features

  • Focused 90° x 50° dispersion suits longer-throw and cluster applications
  • Rotatable horn supports horizontal or vertical cabinet orientation
  • Velocity-compensated porting delivers extended low-frequency performance from a compact enclosure
  • Full-bandwidth overload protection supports reliable long-term operation without audible effect
  • Weatherised components and a multilayer grille with hydrophobic cloth support indoor and outdoor installation
  • Colour Black
  • Impedance 8 ohm
  • IP Rating IP44
  • Sensitivity 94 dB
  • Warranty 3 Years
  • PRODUCT TYPE 2-WAY INDOOR/OUTDOOR INSTALL LOUDSPEAKER
  • Brand ELECTRO VOICE
  • Config 2-WAY
  • Driver Size 8"
  • Power Type PASSIVE
  • Mount Type SURFACE MOUNTED
  • SPL (DB) 94
  • Dispersion Angle 90H X 50V
  • Voice Coil Size 1.25"
  • Input Connector 4-PIN PHOENIX CONNECTOR
  • Peak Power (W) 800W
  • Weight (kg) 10.4 KG
  • HF Driver Size 1"
  • LF Driver Size 8"
  • Enclosure HIGH IMPACT POLYMER
  • Max SPL (dB) 123 DB
  • Hertz 48-20000HZ (-10dB)
  • Max Wattage 200W
  • Max 100V Tap (W) 100W
  • 100V Taps List 12.5W; 25W; 50W; 100W; 8 OHM
  • Max 70V Tap (W) 100W
  • 70V Taps List 6W; 12.5W; 25W; 50W; 100W; 8 OHM
  • Unit Dimensions (mm) 451H x 282W x 263D
  • Crossover Freq 1.7KHZ
  • Program Power (W) 400W
  • Series ZX1i
  • Arrayable Yes
