> >>HH MZ-140Q 140W 4 ZONE POWER AMPLIFIER BLACK
FOUR ZONE MATRIX POWER AMPLIFIER - 4 X 140 WATT View larger
Previous Next

HH Electronics

HH MZ-140Q 140W 4 ZONE POWER AMPLIFIER BLACK

HHAMZ-140Q

MZ-140Q

New product

HH ELECTRONICS MZ-140Q POWER AMPLIFIER 4X140W 70V 100V 4 OHM 1U BLACK

More details

Balcatta: 0
Geebung: 0

MZ-140Q 4 Zone Power Amplifier 4x140W

The MZ-140Q features four individual 140 Watt RMS Class D power amplifiers and each amplifier can be configured to run 70/100 Volt or at minimum 4 Ohm impedance. Each amplifier is a zone, with front panel controls for volume, two band EQ and source select per zone.

There are five flexible input channels, each with a front panel mounted gain trim control. Dual combi microphone inputs allow two individual microphones to be connected simultaneously, both with auto or manual priority modes. Built in a full size 1U rack case, the unit is extremely robust with easily operable controls. Front scribble strips allow the installer to easily identify each zone and input. The perfect installation amplifier for retail, leisure, cafes, bars and halls.

Key Features

  • 4 zone amplifier
  • 4x 140 Watts RMS power output
  • Supports 70/100V or minimum 4 Ohm impedance speaker outputs, configurable per zone
  • 5 comprehensive audio input channels
  • Independent bass and treble EQ adjustment on each zone
  • Compact space saving 1U design, rack mountable
  • Universal 100-240V worldwide operation
  • Remote volume control capability using HH MZ-C2 module and standard ethernet cable
  • PRODUCT TYPE POWER AMPLIFER
  • COLOR BLACK
